Weight: 10 kg
Dimensions (LxDxH): 29.5 x 25.5 x 35.5 cm
Frequency Response (@ +/-3dB): 50 to 20 kHz
Sensitivity (1W/1m) @1 kHz: 89 dB
Power: 100 W pure analog power amp
SPL Max: 108 dB
Speakers: 1” dome tweeter, 6” woofer
Construction: 12 mm birch BB laminated
System - Format: Two way, bi-amplified - Bass reflex
Mic In connector: XLR
Mic In sensitivity: -52 dB
Mic In impedance: 4.7 kΩ
Instrument In connector: 1/4" jack unbalanced
Instrument In sensitivity: -47 dB
Instrument In impedance: 820 kΩ
Stereo In connector: 1/8" jack stereo
Stereo In sensitivity: -10 dBu
Stereo In impedance: 40 kΩ
Insert: On master
Line Out connector: 1/4" jack
Line Out level: 0 dBu
Line Out impedance: 200 Ω
DI Out connector: XLR
DI Out level: -∞ to +6 dBu
DI Out impedance: 180 Ω
Aux Out connector: n.a.
Aux Out level: n.a.
Aux Out impedance: n.a.
Phones connector: n.a.
Phones level: n.a.
Phantom Power (nominal): 24 VDC
Stat Power (10 VDC): Yes
Effect: Spring-type digital reverb
Preamp: Class-A, no negative feedback, no integrated circuits
Footswitch: n.a.
Stand mounting: Flange mount ø 36 mm, h=102 mm
Available versions: Light wood and anthracite
|
