Weight 12.2 kg
Dimensions (LxDxH) 32.4 x 29.7 x 38 cm
Frequency Response (@ +/-3dB) 40 to 20 kHz
Sensitivity (1W/1m) @1 kHz 92 dB
Power 200 W pure analog power amp
SPL Max 114 dB
Speakers 1” dome tweeter, 8” woofer
Construction 12 mm birch BB laminated
System - Format Two way, bi-amplified - Bass reflex
Mic In connector XLR
Mic In sensitivity -52 dB
Mic In impedance 4.7 kΩ
Instrument In connector 1/4" jack unbalanced
Instrument In sensitivity -47 dB
Instrument In impedance 820 kΩ
Stereo In connector 1/8" jack stereo
Stereo In sensitivity -10 dBu
Stereo In impedance 40 kΩ
Insert On master
Line Out connector 1/4" jack
Line Out level 0 dBu
Line Out impedance 200 Ω
DI Out connector XLR
DI Out level -∞ to +6 dBu
DI Out impedance 180 Ω
Aux Out connector 1/4" jack unbalanced
Aux Out level 0 dBu
Aux Out impedance 200 Ω
Phones connector n.a.
Phones level n.a.
Phantom Power (nominal) 24 VDC
Stat Power (10 VDC) Yes
Effect Spring-type digital reverb with decay
Preamp Class-A, no negative feedback, no integrated circuits
Footswitch n.a.
Stand mounting Flange mount ø 36 mm, h=102 mm
Available versions Light wood and anthracite
|
